Engineered for versatility in orthopedic, abdominal, and specialized surgeries, ensuring stability and C-arm imaging access.
Features an advanced electric-hydraulic control system for smooth, low-noise, and stable adjustments during procedures.
The tabletop's longitudinal sliding movement up to 300mm provides excellent C-arm access without repositioning the patient.
Constructed with a high-quality 304 stainless steel base and column for exceptional durability and ease of cleaning.
Includes a manual handset and a column handset, offering dual control systems for operational flexibility.
The memory foam mattress is seamlessly sealed to be waterproof, antibacterial, and easy to sterilize.
Modular design with interchangeable head and leg sections to accommodate a wide range of surgical procedures.
Overall Dimensions: 2050mm (L) x 500mm (W)
Height Adjustment Range: 750mm to 1050mm
Trendelenburg/Reverse-Trendelenburg: 20°/15°
Lateral Tilt (Left/Right): 18°/18°
Back Section Adjustment: Up 65° / Down 15°
Patient Weight Capacity: Approximately 250kg
